Automatic Changer Tool Cnc Machine

We are instrumental in providing to our valuable customers excellent quality Automatic Changer Tool CNC Machine which is available with following Key Features:
Seamless steel structure
9kw HSD air cooled spindle
Rotary auto tool changer on the gantry
Powerful Yaskawa AC Servo drive motors
Circular auto tool changer with 8 positions
Helical rack and pinion
Re-carving after power failure
Well compatibility: type3, castmate, Artcam, etc.
H30 Hiwin linear guide

Ideal for:
Furniture manufacturing
Advertisement
Shop fitting
Woodworking
Density board
Acrylic
Soft metals
Composite and much more

Processing effect:
Milling, cutting, engraving, drilling, relief, etc.

Specifications:-
Working Area (X Axis) : 1300mm
Working Area (Y Axis) : 2500mm
Clearance (Z Axis) : 300mm
Table Size : 1440mm*3140mm
Precision0.05mm
Spindle : 9kw HSD
Spindle Speed : Adjustable 0-24,000 rpm
Tool Change : Rotary Tool-Change
Drive System (X & Y Axes) : Helical Rack & Pinion
Drive System (Z Axis) : Taiwan ball Screw
Lubrication : Manual oil-injection system
Drive Motors : Japanese Yaskawa servo motors
Driver : Yaskawa
Inverter : Fuling
Reducer : Taiwan planetary gear reducer
Command : G code
Cutter diameter : I 3.175-I 20mm
Maximum Travel Speed : 60m/min
Maximum Engraving Speed : 40m/min
Table Top : Vacuum table with T slots
Vacuum Pump : Chinese Tongyou 5.5kw
Controller : Syntec/Nc Studio
Power Requirements : 3-phase 380V/50HZ (220V/50HZ optional)
Weight : 2200kg
