All Radial Drilling Machine

All radial drilling machine

Specification SMTR-III G/A
Drilling Capacity - 38mm to 40mm
DRILL HEAD
1.Spindle Nose - MT-4
2.Spindle Travel - 220
3.No of Spindle - 8
4.Range of Spindle Speed(RPM) - 90 to 1000RPM
5.Range of Power Feed - (2) 0.20-0.10
POWER
1.Main Motor (1.5 HP ) - 1400KW/RPM 1.55/2800 KW/RPM
2.Arm Elevating Motor (0.5 HP) - A-23 V-Belt
WORKING TABLE
L x W x H - 380 x 300 x 300
WORKING RANGE
1.Drilling Radius Max./Min. - 895/440
2.Max./Min.Dist.Column to Spindle - 850/275
3. Max.Drill Head Drive - 450
4.Max./Min. Base Plate to Spindle -930/230
5.Diameter of Column -168
BASE PLATE
L x W x H -760 x 1250 x 150
Working Surface -820 x 610
No. of T-Slot -4
DIMENSION
Overall Heighta 2000
Wooden Case(L x W x H) -1250 x 1550 x 2000
