30seg 87mm Led Bargraph Module

We are engaged in offering excellent quality 30seg 87mm LED Bargraph Module to our valuable clients. These Bargraph Indicator Meter is the novel indicator meter provided a bright, easy to read display of current, voltage, temperature, power or other process parameters.

Feature:
1 high visibility
2 high brightness
3 multi angle visible
4 single bar configuration

Specification
Model: AP2101F314Z
Bargraph: 101x2segment
Panel size : 36mmx144mm
Color: red&red
Environment: -10--70A C
Dimension: panel design to standard DIN 36 x 144mm
Input type: current, voltage, resistor or Pt100
Input: 4-20mA or 1-5V or 0-5V or 0-10mA (optional)
Power supply range: DC10-26V / AC220VA 10% AC86-260V (optional)
Zero & full adjust rate: A 10--20%
Power consumption: a 1.5W(F.S)
Housing material : gray plastic

Symbol absolute maximum rating(TA= 25C )
Peak forward current : 30~100mA
Reverse voltage : 5V
Power dissipation : 0.1 ~ 0.2 W(F.S)
Operating temperature range : -25 ~ 70 A C
Soldering time at 260A C : 3sec

Electro-optical characteristics
Red Green Orange
625nm 570nm 590nm
50mcd 45mcd 50mcd
1.9V 2.0V 2.0V
