2 Function Electric Linear Actuator - Ambient Temperature: 0 C To 50 C Celsius (Oc)

2 Function Electric Linear Actuator (Stroke 100 mm | Load 6000 N | Speed 4 mm/s)

This dual-function hospital-bed linear actuator system is designed to provide independent adjustment of the back-rest and leg-rest sections. It delivers smooth, quiet, and precise linear motion, ensuring enhanced patient comfort and caregiver convenience. The system includes a wired control unit and handset for simple and reliable operation. Suitable for both hospital beds and home-care beds.

Technical Specifications

• Power Supply: 24V DC


• Actuator Power Rating: 60 W


• Stroke Length: 100 mm


• Full Length: 100 mm 288 mm


• Maximum Load: 6000 N


• Speed: 4 mm/s


• Noise Level: 54 dB


• Duty Cycle: 20%


• Control Method: Manual


• Communication: Wired


• Built-in limit switches


• Overload protection


• Operating Temperature: 0C to 50C


• Operating Humidity: 10% to 90% (Non-condensing)

Key Benefits

• Independent back-rest and leg-rest adjustment


• Smooth and precise movement


• Quiet operation for patient comfort


• High load capacity for reliable performance


• Easy-to-use wired handset
