Yarn Twisting Machine - 32 Spindles, Max 256 Spindles, 8000-13000 R/min Rotating Speed, Magnetic Force Fixing, Adjustable Twist Range Up To 3898 T/m

We are manufacturing, exporting and supplying a wide range of Yarn Twisting Machine in Wuxi, Jiangsu, China, which are available following Specifications:-
Spindle Number: 32- Spindle Multiplication (Max.256 Spindles to Standard)
Spindle: I 90 Conical Spindle
Spindle Distance: 225mm
Usual Rotating Speed: 8000-13000r/min
Twist Range: 350-3898T/M
Twist Direction: s or z
Unwinding Bobbin Specification: I 100A I 42A L240-270
Winding Capacity: 750g-1200g
Winding Method: Edged Bobbin Parallel Winding
Spindle Transmission Method: Tangential Belt transmits in cycles
Spindle Fixing Method: Magnetic Force
Starting Method: Y-a Slow starting
Tensioner: Elastic Tensioner and Cushion Tensioner are put in use together
Winding-Up Tension: Overfeed Rate-Regulating and Tensioner Device
Winding Angle: standard 3A 42a blinks (9.0 time/single stroke) 2A 51a blinks (11.7 time/single stroke) 6A 42a blinks (5.0 time/single stroke)
Applicable Range: 25D-500D chemical fiber yarns
Operating Method: Two Side, Two Layers Low Machine Body
Transmission Motor: 2A 7.5KW
Working Environment Condition: Relative Humidity a 90% Temperature 30a
Outside Dimension: 11600A 900A 1850mm

We produced all the key parts of the machine by ourself, especially for spindles
