Winding Rewinding With Batch Printer - Max Web Width 450 Mm, 2 Hp Ac Motor, 20-155 Mpm | Batch Printing, Automatic Control, Reject Removal, Precise Tension

We are one of the well-known manufacturers and suppliers a wide range of Winding Rewinding With Batch Printer in Vadodara, Gujarat, India. The offered doctoring rewinding machine is very commonly used for rewinding of paper, foil and films. Our supplied doctoring rewinding machine with Batch Printner is capable of removing the rejected material. The offered doctoring rewinding machine with Batch Printer is easy to operate.

Application:-
Multiline Packaging and Printing Machine for Rapper Film, Foil and Pouch Online Printing of MRP, MFG Date, Exp. Date, Batch No.
Specification:
AC Motor: 2 HP 950 RPM.
AC Drive: 2 HP with Torque Motor.
Web Guide Motor: 0.5 HP with 1450 RPM.
Max Web Width: 450 MM.
UW/RW Shaft: Mechanical Expandable/Tapper Cone.
Winding Speed: 20 - 155 MPM.
Rewind / Unwind Core Dia: 76 MM Standard.
Max Rewind / Unwind Dia : 450 MM.
Line Speed Control: Automatic.
Salient Feature:
Advanced Design for Efficient Power Consumption.
Hydraulic Web Guide System.
Tension Controlled By Manual Break.
Provision For Incorporating Inkjet Printing System.
Advance Structure Design For Vibration Free Working.
Rubber Cork Material For Avoid Slippage.
Clear Roll Paper Winding & Finishing.
