Wheel Loader - 18676 Kg Operating Weight, 2.5-4.4 Mâ³ Bucket Capacity | High Operational Fluency, Energy Efficient, Simple To Operate
Price:
Get Latest Price
In Stock
Product Specifications
| Models | Paj603, Paj603M, Paj1003, Paj1003M, Paj2003, Paj2003M |
| Readability | 0.001/0.0001 Ct/G |
| Capacity | 625/125 Ct/G |
| Weighing Pan | 90 Mm |
| Materials | Cast Aluminum |
| Dimensions | Variable |
| Weight | 100G, E2/200G, F1 |
| Features | Accurate Weighing, Durable Design, Easy To Use, Multiple Units, Fast Results, Reliable Performance, Backlit Display, Rs232 Output |
Product Overview
Key Features
Driven by an ingenious team of professionals and
advanced production unit, we have been able to offer Wheel Loader to
our clients. Widely
demanded in automobile, construction, and other industries, this loader is
basically used for material handling equipment for high speed loading and
unloading operations. The provided loader is designed and manufactured by vendorsa
skilled professionals using supreme quality components and sophisticated
techniques. Additionally, we are offering Wheel
Loader to our customers at industry leading prices.
Features:
- Fitted with loader
- High operational fluency
- Energy efficient
- Simple to operate
Overview
The new Wheel Loader is designed specifically to handle all the jobs on your work site from material handling and truck loading, to general construction, to stockpiling. This machine is purpose built to be just the right machine to get your everyday jobs done. Great machine performance combined with low owning and operating costs make the 950 GC wheel loader the right choice for your business.
Engine
| Net Power - ISO 9249 | 151.0 kW |
| Engine Model | CatA AR C7.1 |
| Bore | 105.0 mm |
| Stroke | 135.0 mm |
| Displacement | 7.01 L |
| Max Gross Power @ 2,000 rpm - ISO 14396 | 171.0 kW |
| Max Gross Torque @ 1,400 rpm | 1020.0 NA A.m |
| Max Net Torque @ 1,300 rpm | 931.0 NA A.m |
| Rated Gross Power @ 2,200 rpm - ISO 14396 | 168.0 kW |
| Rated Net Power @ 2,200 rpm - ISO 9249 | 151.0 kW |
Weights
| Operating Weight | 18676.0 kg |
Buckets
| Bucket Capacities | 2.5 m3 to 4.4 m3 (3.3 yd3 to 5.75 yd3) |
Operating Specifications
| Breakout Force | 147.0 kN |
| Note | **Compliance to ISO (2007) 14397-1 Sections 1 thru 5. |
| Note | *Full compliance to ISO (2007) 14397-1 Sections 1 thru 6, which requires 2% verification between calculations and testing. |
| Static Tipping Load Full 40A A Turn - ISO 14397-1* | 10503.0 kg |
| Static Tipping Load Full 40A A Turn - Rigid Tires** | 11197.0 kg |
Transmission
| Forward 1 | 7.0 km/h |
| Forward 2 | 12.5 km/h |
| Forward 3 | 22.0 km/h |
| Forward 4 | 34.0 km/h |
| Reverse 1 | 7.0 km/h |
| Reverse 2 | 12.5 km/h |
| Reverse 3 | 22.0 km/h |
Hydraulic System
| Steering System Pump Type | Piston |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.8 Seconds |
| Hydraulic Cycle Time - Dump, at Maximum Raise | 1.2 Seconds |
| Hydraulic Cycle Time - Raise from Carry Position | 6.1 Seconds |
| Hydraulic Cycle Time - Total Cycle Time | 10.1 Seconds |
| Implement System Pump Type | Piston |
| Implement System - Maximum Operating Pressure @ 50 A A 1.5 L/min | 27900.0 kPa |
| Implement System - Maximum Pump Output @ 2,200 rpm | 248.0 L/min |
| Implement System - Optional 3rd Function Maximum Flow | 280.0 L/min |
| Implement System - Optional 3rd Function Maximum Pressure @ 70 L/min | 20680.0 kPa |
Brakes
| Brakes | Brakes meet ISO 3450 |
Tires
| Choices | Choices include: 23.5-25 16PR, L3 (Triangle); 23.5R25 AcE a AcE a , L3 (Triangle); 23.5R25 AcE a , L3 (Bridgestone) |
Cab
| ROPS/FOPS | ROPS/FOPS meet ISO 3471 and ISO 3449 Level II standards |
Service Refill Capacities
| Cooling System | 48.0 L |
| Crankcase | 20.0 L |
| Transmission | 45.0 L |
| Differentials and Final Drives - Front | 40.0 L |
| Differentials and Final Drives - Rear | 38.0 L |
| Hydraulic Tank | 120.0 L |
| Fuel Tank Size | 290.0 L |
Dimensions
| B-Pin Height | 4188.0 mm |
| B-Pin Height @ Carry | 655.0 mm |
| Lift Arm Clearance | 3649.0 mm |
| Height to Top of ROPS | 3458.0 mm |
| Height to Top of Exhaust Pipe | 3596.0 mm |
| Height to Top of Hood | 2568.0 mm |
| Ground Clearance | 460.0 mm |
| Center Line of Rear Axle to Edge of Counterweight | 2001.0 mm |
| Wheelbase | 3300.0 mm |
| Center Line of Rear Axle to Hitch | 1650.0 mm |
| Rack Back @ Maximum Lift | 60.0 Degrees |
| Dump Angle @ Maximum Lift | 52.0 Degrees |
| Rack Back @ Carry | 45.0 Degrees |
| Rack Back @ Ground | 40.0 Degrees |
| Height to Center Line of Axle | 750.0 mm |
Turning Radius
| Turning Radius to Inside of Tires | 3419.0 mm |
| Turning Radius to Outside Edge of Counterweight | 6190.0 mm |
| Turning Radius to Outside of Tires | 6164.0 mm |
| Width Over Tires | 2745.0 mm |
