Welding Rectifier By Esab India Limited

RS 400 is designed for performance and economy in the most demanding welding applications, from heavy duty shop floor fabrication to project site applications. Excellent pipe welding quality, even with long cables makes it the machine for all applications.

Salient Features :
Immunity from AC input fluctuation of A 10% with built-in overload and thermal cut out protections
In-built hot start facility ensures easy arc striking
Single range current control with optional remote control facility
Ideal welding current characteristics with higher open circuit voltage
Low power consumption
Ideal for TIG welding with suitable accessories

Technical Specifications :
Supply Voltage : RS 400 Thyristorised Welding Rectifier
Rated Input Current : 415 +_ 10%, # Phase, 50 Hz AC
Rated Input KVA : 27 Amps
Output Current Range : 30 - 400 Amps DC
Rated current at 60% duty cycle : 270 Amps
OCV : 90 V
Welding Current Control Type : Steples (Remote control optional)
Insulation Class : 'H'
Cooling Type : Forced Air
Dimension (L x W x H) : 825 x 695 x 1070 mm
Weight (approx.) : 195 Kgs.
