Viscous Liquid Packing Machine - 900 Pouches/hr Production Speed, 200ml-1000ml Filling Capacity, Volumetric Piston Filling System, Plc Controlled Operation

• Production speed                                      : 900 pouches/hr (Depending on product)

• Packing range                                           : 200ml-1000ml
• Power requirement                                    : 1Ø, 230V/440V , 50Hz +/-5%
• Machine Dimensions                                 : 800(W) x1100(D) x 2200(H) Approx
• Net weight                                                 : 600 kg (Approx)

Model : SUN FLEX- VLS-1000

System : Mechanically operated Automatic Form, Fill & Seal Machine

Product : Viscous Oil, Arrack

Film Size : Normally 325mm

Filling Capacity : From 200ml to 1000ml

Filling System : Volumetric

Fill Accuracy : +/- 1%

Fill Speed : 09 – 12 pouches per minute depends on Polythene

Sealing System : Impulse sealing

Seal Type : Centre Seal/Side seal

System of Operation : P.L.C control

Motor : Any reputed make

Reduction Gear Box : Standard 30:1 Reduction Ratio

Power : 230 V/440 V,+/-10V,50Hz, 3PH/1PH.

Power Consumption : 2.5 KW/HR

System Weight : 450 Kg’s. (Approx)

System Dimension : W x H x D (Approx.) 850mm x 1800mm x 950mm

Material of Construction : All parts coming in to contact with the product ASI 304 Stainless steel and

others are mild steel duly painted.
