Vg-c04w-16e Vision Sensor - Material: Plastic

Min. sensing distance : 100mm
Power supply : 24VDC @(=) A 10%
Current consumption : 1A
Inspection Inspection item : Alignment, brightness, contrast, area, edge, shape comparison, length, angle, diameter, object counting, color identification, area of color, object of color counting
Inspection Work group : 32
Inspection Simultaneous inspection : 64
Inspection Camera frame per second : Max. 60fps
Image snap Image filter : Preprocessing, external filter(color filter, polarizing filter)
Image snap Image element : 1/3 inch color CMOS
Image snap Resolution : 752A 480 pixel
Image snap Camera frame per second : Max. 60fps
Image snap Shutter : Global shutter
Image snap Exposure time : 20 to 10,000???
Light ON/OFF method : Pulse
Light Color : White
Trigger mode : External trigger, internal trigger, free-run trigger
Input Signal : Rated input 24VDC @(=) (A 10%)
Input Type : External trigger input(TRIG), encoder input(IN2, IN3), work group change(IN0 to IN3)
Output Signal : NPN or PNP open collector output
Max. 24VDC @(=) 50mA, residual voltage: max. 1.2VDC @(=)
Output Type : Control output(OUT0 to OUT3): inspection completion, inspection result, external light trigger, alarm, camera busy
Output FTP transmission : Possible
Protection circuit : Output short over current protection circuit
