Vertical Long Shaft Pump By Maacturbo Process Equipments Private Limited

Vertical single stage sump pump compliant with ISO 5199 and optional features with API 610 bearing spans.

The vertical sump pump incorporating best in class hydraulic design for efficient and reliable service. The vertical sump pump can be customized to meet a wide range of needs. Compliance with ISO 5199 and available in wide range of hydraulic wet-ends and a wide variety of materials of construction. It is also available with multiple mechanical seal options and sump depths.

Single stage vertical centrifugal pump
Radially split casing with flanged connections
Cast iron or cast steel motor support assembly
Column and discharge pipe assembly, Sole plate mounted
Enclosed impeller, Open and Semi Open impeller based on application need.
Bearing housing with bronze guide bearings (optional materials available)
Labyrinth oil seal at bearing housing (optional design)
Grease lubricated thrust bearing (standard) or oil lubricated thrust bearing (optional)
Gland Packed / many optional mechanical seal types available
Maximum of 4 m sump depth can be offered.
Benefits-
Back Pull-Out design for ease of maintenance allows easy maintenance.
Optimum Efficiency
Various materials of construction available
Durable Mechanical seal
Compact design
Thrust Bearing
Grease Lubricated
Oil Lubricated
Oil mist lubrication technologies
Radial Bush Bearing
Product Lubrication
Optional fluted rubber with rigid shell, bronze, carbon and other special alloys are available. Petro-coke cartridge is also available.
Material of Construction:
Stainless Steel SS316
Stainless Steel SS304
Duplex Stainless Steel
Super Duplex Stainless Steel
Nickel Alloy
