Universal Tool Grinding Machine

The Universal Tool Grinding Machines are specially suitable for sharpening tools in HSS, tungsten carbide and other materials, also for cylindrical, surface, slot and profile grinding work. By using additional attachments, you greatly extend the range of application of there machinery and can solve individual machining problems, such as grinding of various hobs, for tools, spherica cutters, twist drills and steep taper reamers, etc. The series machine wheelhead with two-dimensional setting , workhead stock swivels with double dir., And supplied with ISO-50 taper hole. Worktable is supported in preloaded ball guide and can be driven by hand or by infinitely changing rate hydraulic.

MA6025 Technical Data:
Max. swing dia. of workpiece : 250mm
Max. distance between centers : 650mm
Area of the operating table : 940*135mm
Max. longitudinal travel of table : 480mm
Max. swing angle of table : A 60degree
Max travel of wheel head cross vertical : 230mm
Max. swing angle of wheel head in horizontal plane in vertical plane:360degree
Max. swing angle of wheel head in the longitudinal plane in vertical Plane : 30degreeA 15degree
The taper of the spindle end : MT NO.3
Main motor power : 50Hz,0.75/1.1KW
The Speed of Grinding wheel : 1400/2800RPM
The speed of Motor : 3050/6095RMP
The Motor of Cylindrical grinding attachment : 50Hz,0.12KW
The size of the machine : 1460*1102*1240mm
The weight of the machine : 1000KG
