U Tube Double Column Manometer - Inclined Design For Enhanced Accuracy | Meteorological Instrument For Differential Pressure Measurement
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Teknik
In Stock
Product Specifications
| Humidity | 0-80% RH (Non-condensing) |
| Usage | Meteorological Instruments |
| Accuracy | A+-1 mm or better |
| Max Height | 300 mm scale or as specified |
| Resolution | 1 mm |
| Test Range | 0-300 mm WC (customizable) |
| Display Type | Visual Liquid Column |
| Gas Pressure | Up to 0.6 kg/cmA2 or custom |
| Product Type | U Tube Double Column Manometer |
| Temperature | Operating: 0AdegC to 50AdegC |
| Port Size | 1/4 inch BSP or custom (as per requirement) |
| Power Supply | Not Required (Manual Operation) |
| Number of Specimens | Single |
| Response Time | Instantaneous (as per liquid movement) |
| Application | Meteorological Instruments |
| Mounting Type | Wall or Panel Mountable |
| Automation Grade | Manual |
| Measuring Range | 0-300 mm WC (standard) |
| Features | Transparent scale, double column, wall-mountable, chemical-resistant tube |
| Interface Type | Manual/Analog |
| Equipment Type | U Tube Double Column Manometer |
| Capacity | 0-300 mm WC or as specified |
| Machine Weight | Approx. 1-2 kg |
| Control Mode | Manual |
| Supply Ability | 100 Per Week |
| Delivery Time | 1 Days |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Export Market(s) | Middle East, Africa, Asia, North America |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
Micro Teknik
The pressure difference in a inclined u-tube can be expressed as
pd = h sin()
where
h = length, difference in position of the liquid column along the tube (mm, ft)
= angle of column relative the horizontal plane
Inclining the tube manometer will increase the accuracy of the measurement.
Example - Differential Pressure Measurement with an Inclined U-Tube manometer
We use the same data as in the example above, except that the U-Tube is inclined to 45o.
The pressure difference head can then be expressed as:
pd = (9.8 kN/m3) (103 N/kN) (10 mm) (10-3 m/mm) sin(45)
= 69.3 N/m2 (Pa)
