Two Stage Rc Coupled Transistor Amplifier
Get Latest Price
Minimum Order Quantity :
10 Unit
Brand Name :
Edutek
In Stock
Product Specifications
| Output | Amplified audio/signal output |
| Usage | Signal amplification in electronic circuits |
| Thermal Conductivity | Standard PCB thermal conductivity |
| Resolution | Analog signal (not digital) |
| Input | Audio/signal input via capacitor |
| Power Source | 12V DC adapter |
| Response Time | Instant (in milliseconds) |
| Power Supply | External 12V DC source |
| Interface | Terminal blocks for input/output |
| Components | Resistors, capacitors, two general purpose NPN transistors, PCB |
| Features | 2-stage amplification, RC coupling, compact PCB, test points |
| Operating Temperature | 0AdegC to 50AdegC |
| Product Type | Discrete Transistor Amplifier Module |
| Application | Laboratory experiments, training kits, small audio systems |
| Rated Voltage | 12V DC |
| Supply Voltage | 12V DC |
| Size | Compact module size |
| Dimension (L*W*H) | Approx. 100 mm x 70 mm x 20 mm |
| Function | Amplifies weak audio or signal currents |
| Color | Green & Black (PCB and components) |
| Weight | Approx 60 grams |
| Capacity | Handles signals up to 1Vpp |
| Thickness | PCB: 1.6 mm |
| Current Rating | Approx. 30 mA |
| Frequency | 20 Hz to 20 kHz |
| Payment Terms | Telegraphic Transfer (T/T), Cash Advance (CA), Letter of Credit (L/C), Cash in Advance (CID), Cheque |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Export Market(s) | Eastern Europe, Middle East, Western Europe, Asia, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
