Turbo Injection Mill

We manufacture, export and supply Turbo Injection Mill (Lab. Horizontal Bead Mill) that is designed to make small laboratory dispersion samples while using minimum amount of raw materials. Herein, the samples are grounded, premixed, poured into feeding funnel. These materials further moved into water cooled milling chamber having 70-85% of the void volume with small grinding beads approximately 1 mm diameter. The rotation of the agitator and subsequent movement of the media creates shear and impact forces upon the turbo-injection concept for efficient particle and agglomerate reduction. A screen located at the chamber end retains the beads while the diverter end plate allows the product to either re-circulate back to the feed funnel or exit in a single pass. Samples can be taken at intervals and tested for quality.

Why our Turbo-Injection Mill?
Speedy solution to testing difficulties
Handling of wide range of viscosities
Easy to dismantle and reassemble
Require low maintenance
Competitive pricing

Fast Features:-
Efficient development of new formulations
Reliable raw materials quality control
Rapid assessment of customer problems
Speedy solution to testing difficulties
Handling of wide range of viscosities.
