Triplex Reciprocating Pump - 200 Bar Max Pressure, 30 Lpm Flow Rate | Solid Ceramic Plungers, Forged Brass Pump Head, High Wear Resistant Alloy Steel Components

We are prominent manufacturer, supplier and exporter of Triplex Reciprocating Pump in Ahmedabad, Gujarat, India. This Triplex Reciprocating Pump is design with pre set packings & ceramic plungers to provide high pressure up to 200 BAR & Flow Rate up to 30 LPM. The advantages of Triplex Piston Pumps in their high efficiency, their ability to generate high pressure and to produce constant volume irrespective of the pressure. Consequently, where an application demands controlled variable flow, they are eminently suited to variable speed drives. Using a Triplex High Pressure Pump with a variable speed drive can provide very high efficiencies, up to 95% depending on the pump type design and how it has been installed, across a wide range of flow rates and pressures.

Technical Specification:
Model No: NLTI-30.200
Flow Rate: 30 LPM (7.93 GPM)
Min. Pressure: 90 BAR (1300 PSI)
Max. Pressure: 200 BAR (2900 PSI)
Motor (HP): 7.5HP~17.5HP (Standard / Flameproof)

Technical Features about Plunger Pump:
Pump Head: Forged Brass.
Plungers: Solid Ceramic Plungers.
Pump Main Body: Fully anodized Crankcase.
Connecting Rod: High wear resistant Forged Alloy Steel.
Crank Shaft: High wear resistant Forged Alloy Steel.
Plunger Seal: Improved low and high pressure seals.
Valve Assembly: High wear resistant Stainless Steel.
Oil: 15W40.
