Trimans Variable Rake Angle Nc Hydraulic Shear

Cutting capacity:4 mm to 16 mm. Lengths:2500 mm to 4000 mm Rake angle can be varied through a selector switch on the control panel to facilitate distortion free shearing of thin sheets. Fitted with easy to use single axis nc heavy duty back angle with plc and controller. Suitable for shearing metallic and non-metallic materials and can be easily integrated for on-line shearing applications such as cut to length line, roll forming line, coil built up line, galvanizing line etc. Top beam is guided by three point roller guides with replaceable hardened liners for least wear. This eliminates lubrication of guides. Clearance between top and bottom blade can be adjusted without feeler guages from minimum 0.05 mm (required for shearing upto 32 swg sheets) to that required for maximum rated capacity manually by levers. Built-in over load protection protects the machine and the blades against damages due to overload. Less power consumption, least wear and tear and minimum maintenance reduces operating costs and down time. Noiseless, vibration free operation improves working atmosphere. There is no reduction in capacity due to periodical wear hence unlimited service life is obtained. The stroke length is adjustable according to the job length reducing idle travel and increasing productivity for smaller jobs.
