TRIAC CHARACTERISTICS
Objectives: To observe the forward and reverse bias V-I Characteristics of TRIAC and plot the graph, and to observe the break over voltages of TRIAC.
This unit consists of a variable power supply of 0-35V,0-12V,300mA,fixed AC power supply,18V,250mA.
The trainer constructed with TRIAC with variable Load, also one DC lamp application board in built.
The Circuit layout is designed on FR-4 type Glass Epoxy PCB with masked copper track lines.
All testing points are Provision with 2mm socket for proper connectivity.
Set of 2mm patch cards and user manual is accompanied with this kit.
