Titanium Gold Coating Machine

We are instrumental in providing to our valuable customers excellent quality Titanium Gold Coating Machine which is available with following specification:-
Model: TG-2023
Size:I 2000A H2300mm
Power: 185-200kw
Occupied Area: 35-55mA
Arc Source: 22-28sets
Coating Film: Decorative Coating
Advantage: High ionization rate, high deposition rate, stability and low temperature to magnetron sputtering, fine particles, simple operation, high yield etc.

Application:
1. Hardware industry (sanitary ware, door handles, handle, door locks etc.)
2. Decoration industry (stair handrail)
3. Household appliances (logo label, signs)
4. Stainless steel products (exhibition shelf, frame)

Color: gold, rose gold, black gold, silver, champagne gold, sapphire blue, black, etc.
Coating: TiN,CrN,ZrN,TiCN,TiCrN,TiNC,TiALN and DLC
Remark: Specially tailored according to customersa products and process requirements.

Working Principle: The Cathode combine with the Anode to form the arc discharge in vacuum environment, then release the ion from the Cathode.
Due to the concentration of the current, It will produce the heat which will make the material plasma. The plasma react with the gas under the action of the sputter bombardment, to be coated at the surface of the products.
