Thermocouple Calibration Furnace - 150°c - 1300°c, Microprocessor Pid Controller, High Purity Ceramic Tube Design, Concentric Shell Construction

We are counted among the prominent organizations engaged in manufacturing and supplying a superior quality spectrum of Thermocouple Calibration in New Delhi, Delhi, India. Constructed using a metallic sheath and high purity mineral oxide insulation, the Thermocouple Calibration Furnace comprises a number of concentric shells. Thermocouple Calibration Furnace possesses high insulation resistance making it suitable for most process applications in different laboratories. The precise design Thermocouple Calibration Furnace ensures a central zone of constant temperature.
Specifications 150A C. a 1100A C.
Outside Dimensions : 450 x 450 x 600 mm
Internal Volume : 50 mm A x 200 mm hot zone x length 600 mm
Ceramic Tube : Internal A 50 mm x length 600 mm
Power : 230V A 10% 50/60 Hz20 A max
Thermocouple : CR/AL
Thermocouple Block : 48 mm A x 200 mm length, provision for testing 5 Thermocouples at a time (3, 6, 8, 10 & 12.5 mm)
Controller : Microprocessor Based PID
Cut out Probe / Control Probe : K-Type

Specifications 150A C. a 1300A C.
Outside Dimensions : 450 x 450 x 600 mm
Internal Volume : 50 mm A x 200 mm hot zone x length 600 mm
Ceramic Tube : Internal A 50 mm x length 600 mm
Power : 230V A 10% 50/60 Hz24 A max
Heating Element : Silicon Carbide / Globar
Thermocouple : PT/PT-RH 13%
Thermocouple Block : 48 mm A x 200 mm length, provision for testing 5 Thermocouples at a time (3, 6, 8, 10 & 12.5 mm)
Controller : Microprocessor Based PID
