Suction Diffuser - Ansi Class 125 & 250 Flanged, Efficient Flow Straightening With Maintenance-friendly Design

To cater the variegated demands of our precious clients, our organization known as a leading Exporter, Manufacturer & Supplier of Suction Diffuser in Bengaluru, Karnataka, India. The Harsha Filters Suction Diffuser incorporates numerous features into one device that simplifies installations and reduces installation costs. It is a flow straightening device that provides maximum flow efficiency at the suction inlet of the pump while at the same time reducing space and fitting requirements and eliminating the need for an equivalent length of ten pipe diameters of straight run on the suction side of the pump. It is an elbow (and in some cases a reducing elbow) with a built in strainer that is easily maintained and will provide years of trouble free system performance.

The Harsha Filters Suction Diffuser is available in a wide variety of sizes.

Working Pressure:
ANSI Class 125 Flanged units - 175 psi working pressure
ANSI Class 250 Flanged units - 300 psi working pressure
All Grooved units suitable for all working pressures up to 300psi
Features and Benefits
a cFull Length Straightening Vane Assembly ensures uniform flow to the suction inlet of the pump.
a cOversized Body Cylinder ensures minimal pressure drop
a cMetering Port allows for the monitoring of system conditions
a cDisposable Fine Mesh Start-Up Strainer promotes cleaner more trouble free system
a cRemovable Cover Plate and reusable "O" Ring allows for easy access and maintenance of Permanent Strainer
