Static Dynamic Apparatus

With the assistance of skilled and dedicated professionals, we are eminent Processor, Exporter & Supplier of Static Dynamic Apparatus in Ahmedabad, Gujarat, India. The main element of the bench top unit is a smooth shaft to which four disc with variable unbalance weights can be attached at any angle or distance. The rotor is supported horizontally in ball bearings and is driven by a speed-controlled motor. For determination of the unbalance weight by measuring the balance of moments the driving belt can be removed. Using different weights dragging on the pulley defined moments can be exerted to the shaft. They can be compared with those caused by the unbalance weights when rotating. Fastening of the supporting base with spring neutralizes undesirable vibrations.
Specifications

Table Size: 600 x 300 x 600 mm
1/8 HP 6000 rpm DC Motor with controller
No. of Discs: 4 Nos.
No. of Weights: 8 Nos.
Detailed Technical Manual and On-site Training

Service Required
230 V.A.C. single phase supply.
Rigid platform or sturdy table with preferably a solid foundation.
Hand held Tachometer
