Full Glass Squash Court System - Steel Structure, 6.4m Wide X 9.75m Long, Dark Blue | Easy To Install, Energy-saving Led Lighting, Non-slip Sports Wooden Floor, Shock Absorbing Design

According to WSF Rules, Single Squash Court Dimensions: Width 6.4 m (21 feet) by Length 9.75 m (32 feet ). The Squash Courts Size Complies with WSF squash international rules. we are China Youngman Sports, we are professional suppliers of glass squash court systems .
three walls are made of glass. The front wall is made of 12 pieces of glass with specifications (1750mm*1604mm*12mm). The two side walls are made of 36 pieces of glass with specifications (1750mm*1620mm*12m). The back wall is made of 4 glass walls (2130mm*1402mm*12m), the glass door (2130mm*790mm*12mm). The thickness of the wall glass is 12mm, and the imported materials are specially treated to make the glass achieve a single-view effect. The wall color is (dark blue).
2. The Squash Court System base of the glass wall is connected and fixed with steel plates with specifications of 7400mm*11000m, forming an overall frame that can be disassembled and used repeatedly. The side of the glass wall is supported by glass ribs with a height of 5700mm and a thickness of 12m. The tempered glass must meet the 3c standard.
3. The glass wall and glass ribs of the squash court are connected by aluminum alloy hardware with a thickness of 10m. The surface hardness reaches 15HW,and it has the characteristics of high strength and light weight, making the glass installation more secure and safe.
4. The lighting system is composed of 18 LED lighting groups, which are durable and energy-saving, with an illumination of 500LUX, a voltage of 220V, a power of 100W, an irradiation height of 5.6m, and an irradiation area of 20-25m per lamp.
5. The special floor of the squash court is assembled and installed in 66 pieces. Draw the standard court line. 1 piece,
1 piece of glass is prepared at the highest point of the glass front wall and the highest point of the side wall of the full glass squash court to ensure complete installation.
6. The boundary line is 50m. Equipped with a sound board of 6400mm*480mm*16mm
7. The full glass Squash Facilities System adopts assembly installation.
Special sports wooden floor for squash :
(I) Performance of floor system materials:
Good rebound performance of the ball: shock absorption and earthquake resistance: good sound insulation effect: unique elastic soft pad,
professional squash court sports wooden floor provides unique elasticity and withstands heavy pressure,reducing the chance of athletes being injured by bouncing on the floor.

(II) Construction process:
The panel material is a special sports wooden floor. The training venue adopts fixed installation and the competition venue adopts assembled modular sports floor, which is conducive to quick installation and easy disassembly. (But the ground flatness error does not exceed 3mm/3000mm)
Comply with the a GB/T 20239-2023 Standarda for wooden floors in sports venues, GB/T 19995.2-2005 a Part 2 of wooden floor venues

in comprehensive sports venuesa
1. Impact absorption: a Y53%
2. Rolling load: a Y1500N
3. Vertical curvature: a Y2.3mm
4. Friction coefficient: 0.4-0.6
