Spray Booth - Sandwich Style Design, 8.1x4.0x3.2m External Size, 18000m³/h Air Flow, 7kw Power | Enhanced Drying With Infrared Light Option, Efficient Filtration System

Parameter :
External size(m): 8.1*4.0*3.2
Internal size(m):6.9*3.9*2.7
Door width(m): 3.0
Door height(m): 2.66
Air flow(m3/h): 18000
Inside on-load air speed(m/s): 0.25-0.3
Power(kw):7
Vehicle suited: saloon car
Specification for Spray Booth JNT-101

1. Body
Panel : Sandwich Style,I'=50MM,polystyrene; rock wool as optional
Basement: No
Ramp: No
Front door: 3 pcs of front door without aluminum side cover; one piece of the door is made as emergency door (personnel door)
2. Air System
Hot generator: No ; movable infrared light and railway as optional
Intake fan: No
Exhaust fan: 1 unit of 5.5kw european style big vane fan
Intake duct: No
Exhaust duct: 3M straight ducts,1 90A bend,and one 60A bend
3.Filtration System
Roof Filter: 2 pcs of filter,steel-making and powder coated, mounted above support frame
Exhaust Filtration: Mounted at the rear wall panel
4.Light System
Upper light: 8 sets, 4*40W per set
Side light: No
5.Electric System
Control panel: Components made in China,overload,overheat,
phase-lacking protection,motor direct start.
Power: 7KW
6.Environmental System
Environmental filter: No
Attention: Optional parts are not free.
