Snapdragon 820 Smarc Development Kit

We are engaged in supplying Snapdragon 820 SMARC Development Kit to our clients in Bengaluru, Karnataka, India. The Snapdragon 820 SMARC Development Board incorporates SD820 APQ8096 SMARC SOM which is based on Qualcomm APQ8096 SOC targeted for powering next-generation devices offering many advantages including superior performance, low power consumption, and integrated connectivity. This platform can be used for quick prototyping of any high end applications in verticals like Automotive, Industrial & Medical. The board is highly packed with all necessary onboard connectors to validate complete Snapdragon 820 features.
Highlights:
64-bit Quad Kryo Snapdragon 820 CPU
Adreno 530 3D Graphics @624MHz
Hexagon 680 DSP @ 825MHz
H.265 4K60 decode, 4K30 encode
802.11ac Wi-Fi, BT 4.1 and GPS
5.5a HD AMOLED Display with CAP touch
SMARC R2.0 compatible
Specification:
APQ8096 SMARC SOM:
SD820 64-Bit Quad Kryo CPU (Without Modem)
3GB LPDDR4 RAM
32GB eMMC Flash
Micro SD slot
PCIe to Gigabit Ethernet + PHY
802.11a/b/g/n/ac Wi-Fi + BT4.1 Low Energy (BLE)
GPS/GNSS receiver

SMARC Carrier Board:
Gigabit Ethernet Jack- 1 Port
PCIe x1 slot / MiniPCIe slot - 1 Port1,2
USB 3.0 Host TypeA Connector - 2 Ports
USB 2.0 Host TypeA Connector - 2 Ports
USB 2.0 OTG MicroB Connector - 1 Port
Standard SD slot - 1 Port
HDMI Connector
5.5'' HD AMOLED MIPI DSI display
Capacitive Touch screen
8MP MIPI CSI Camera Connector
Full Function UART - 1 Port
RTC with backup battery
Debug MicroUSB Port
IO Expansion connectors

Power Input: 12V DC
OS: Android Marshmallow
Operating Temperature: 0A C to +70A C
Form Factor: 120mmx120mm Nano ITX Size


Note1: PCIe interface to PCIe x1 slot or MiniPCIe is selectable through control switch

Note2: USB 2.0 Host interface also available on MiniPCIe slot
