Snap Thermostat

The BHA Snap Action Thermostat regulates the temperature continuously by switching the power on and off after the achievement of the set temperature. The Snap Thermostats normally closed contacts opens on achieving the set temperature which closes again when the temperature will drop by the differential.

Technical Specification:
* Function : Single Pole Closed Contacts Opens When The Temperature Is Reached
* Electrical Rating : [Ul & Cul] 125v Ac 9a, 250v Ac 6a, [Vde]250v Ac 6a
* No. Switching of Cycles : [Ul & Cul] 30,000 Cycles, [Vde]1,00,000 Cycles
* Maximum Temperature : [All Standards] 250Ac ? Temp. Setting Range : [All Standards] 0-250Ac
* Tolerance Of Operating Range : +/- 10Ac
* Switching Differential : 10-25k Depending On Mounting And Design
* Turning Angle Range : <= 300A, Reduced Angle Also Possible
* Speed Of Temp. Change : >1k / Min.

Connections: Push on terminal (6.3 mm), M3 screw terminal or Phillips type connections are alternative.
