Smart Podium By Univeso Integrated Solutions Pvt. Ltd.

Our offering range of Smart podium with dual monitor for the first time in the world it is the most leading digital podium system in the age of e-learning
Specifications of AHA Make Smart podium Model (ELF-192D)
BODY
Sliding Cover Opening/Closing the cover easily
Soft Wheels Moving Podium with convenience
Adjusting Monitor Angle System (Actuator)User should set monitor angle as usera s want
Dimensions1130 (W) x 659 (H) x 750 (D) mm
19a LCD Tablet Monitor (Main)
LCDResolution1366 x768
View Area409.8 (H) x 230.4 (V) mm-18.5 inch
Luminance (White)300 cd/m2
Contrast Ratio1000:1 (Typical)
Viewing Angle1600 (H/V)
Lamp Life20,000 Hrs. (min.)
Tablet Technology Electromagnetic Resonance
Detectable Height3~10 mm
Position Report Rate138 pps
Pressure Level1024 Level
19a LCD Monitor (Sub)
LCDResolution1366 x768
View Area409.8 (H) x 230.4 (V) mm-18.5 inch
Luminance (White)300 cd/m2
Contrast Ratio1000:1 (Typical)
Viewing Angle1780 (H/V)
Lamp Life30,000 Hrs. (min.)
Multimedia Controller
VGAVGA Inputs VGA X 2
VGA Outputs VGA X 2
Signal Type VGA, SVGA, XGA, QXGA
Max. Resolution2048 x 1536
Pixel Frequency440 MHz
Control Composite Inputs Video x 2
Composite Outputs Video x 1
Bandwidth100 MHz
Return loss-30 db; 5 MHz
Switch Control Ports X 2
Screen Relay Controls X 2
RFID Control X 1
Serial RS 232 Ports X 4
RMS Control Module X 1
Other Power (Adaptor)12v, 4A
Weight1 kg
7a LCD Control Pad
Resolution800 x 480
View Area154 (H) x 92 (V) mm a 7 inch
