Sk-25f Galvanic Cell Type Oxygen Sensor Accuracy: A 1 Fs %

We are involved in Trading and Supplying SK-25F Galvanic Cell Type Oxygen Sensors in Guangdong, China.

SK-25F Oxygen Sensor Features:
* Virtually no influence from CO2, CO, H2S, NO, H2
* Temperature compensation circuit included
* Good linearity
* No position dependency
* Stable output signal
* No external power supply required for sensor operation
* No warmup time is required

SK-25F Oxygen Sensor Applications:
* Safety - Air conditioners, oxygen detectors, fire detectors, fuel cell systems
* Measurement - Oxygen monitors in flue gas
* Biotechnology - Oxygen incubators, anaerobic cultivators
* Food industry - Refrigeration, greenhouses

The Figaro Oxygen Sensor SK-25F is a unique galvanic cell type oxygen sensor. Its most notable features are no influence from CO2, good linearity up to 30% oxygen, and excellent chemical durability. This feature makes the sensor ideal for oxygen monitoring in various applications such as the biochemical field, food industry, and domestic safety applications.

SK-25F Oxygen Sensor Specification:
Measurement range: 0 to 30% O2
Accuracy: A 1% full scale
Operating conditions
Atmospheric pressure: 1013hPa A 20%
Temperature: -10 to 50 deg C
Relative humidity: 0~99%RH (no condensation)
Response time (90%): a 15 seconds
Initial output voltage under factory test conditions: 5.5~8.5mV
Fcatory test conditions
Atmospheric pressure: 1013hPa
Temperature: 25A 5 deg C
Life expectancy at 20 deg C in normal air: approx. 3 years
