Single Roll Crusher - Alloy Steel Main Shaft | Adjustable Gap Settings, High Tensile Strength, Wedge Shaped Crushing Zone, Pressure And Shear Operation, Versatile For Soft To Medium Hard Materials

We are regarded as reputed providers of a wide gamut of Single Roll Crushers. The single roll crushers that we manufacture are has gained tremendous accolades in the industry for their qualitative features. These crushers find diverse application in varied industry. Some of the applications are like crushing of soft, medium hard and friable materials, like R.O.M. Coal, Rock Phosphate, Soft limestone, Salt Shales, Bauxite, Slag and others.

Drive through counter shaft with gear & pinion arrangement / gear box or through V belts only.

By pressure and shear the crushing of the feed material takes place in the single roll crusher and in a wedge shaped crushing zone. The area of crushing is formed by the rotating roll and the adjustable spring loaded breaker. The gap at the side between the combs of the breaker plate and roll-tips is adjustable on the discharge. The finished product is decided by the gap setting, tooth configuration, surface speed& spring load. Alloy steel of special graded are used to manufacture the main shaft that gives high tensile strength. The breaker plate is fitted on a heavy hinge pin attached to a roller crusher whose lower end is supported by special device. However the position of the roller crushers can be altered.
