Single Phase Induction Motor - M.s. Sheet Metal Fabricated Body, Tefc C.i. Options Available, 0.25 Hp To 3 Hp Capacity, Designed For 230v 50hz

Standard of Manufacture :

BS 2048 Part I : For dimensions of 0.25 hp to I hp motors
IS 996 & IS 1231 : For dimensions above 1 hp to 3 hp motors
BS 5000 Part 11 & IS 996 : For performance

Voltage & Frequency :
Motors are designed for std. 230i? 6% Volts, 50 Hzi? 3% supply. Motors with different voltage (110 Volts) and 60 Hz frequency are available on request.

Motor Frame :
0.25 hp to I hp motors are normally supplied in M.S. sheetmetal febricated body (Frame size B56) with screen protected endshields. However, the above motors can be supplied in Totally Enclosed Fan Cooled (TEFC) C.I. body, if required. Above 1 hp to 3hp the motors are supplied in TEFC C.I.body of 100,112,132 frame.
