Single Action Air Valve - Stainless Steel, 1/2" To 4" Sizes | Excellent Durability, Corrosion Resistance, Application Specific Design
Price:
Get Latest Price
In Stock
Product Specifications
| Body Material | Cast Iron |
| Ball Material | AISI 304 |
| Stem Material | AISI 410 |
| Seal Material | PTFE |
| Thread Type | BSPT/NPT |
| Pressure Testing | 22 Bar |
| Size Range | 15mm-100mm |
| Features | Strong Construction, Corrosion Resistance, Excellent Durability, Easy Installation, High Performance, Anti Corrosiveness |
Product Overview
Key Features
We
are recognized as an affluent entity, affianced in offering a wide assortment
of Single Action Air
Valve to
our clients. With the aid of advanced tools and ultra-modern equipment, our
team of adept professionals manufactures the provided valve using premium grade
raw materials. The offered valve is widely used for controlling and
stopping the flow of various types of fluids. Additionally, our reputed clients
can avail this Single
Action Air Valve in various customized options according to
the needs of our clients
Features:
Application
specific designStrong
constructionCorrosion
resistanceExcellent
durability
Single Action Air Valve
avail from us an exclusive range of Single Air Valve fabricated using quality raw material procured from trusted vendors. These valves are easy to install and find its applications in various industries. These Air Valve are capable to withstand maximum temperature and can operate under most conditions. Durability, high performance, efficiency and anti corrosiveness are some of the highlighting features of these valves. Our customers can avail these valves at affordable prices.
Features
1/2" (15mm) to 4" (100mm) in Screwed type 2pc & 3pc design
Threads as per BSPT / NPT or any other standard can be provided
Can be installed upto 200 degrees centigrade temperature & 35 bar pressure
Indigenously manufactured stainless steel mirror finished balls with 100% accuracy
Blow-out proof stem
Gland packing can be replaced under pressure
Design reference IS:9890 & ANSI B16.1
Mounting flange for actuator as per ISO:5211 can also be provided
Available in Cast Iron, Ductile, Cast Steel, Stainless Steel & Bronze
Available in Full Bore & Reduced Bore
Applications
Plumbing (Hot & Cold Water)
Mining Industry
Construction Industry
Water & Effluent Treatment Plants
Fire Fighting
Heating & Air Conditioning
Gas Supplies
Petroleum & Chemical Industry
Sugar Industry
Solvent Plants
Distribution of Oils
Boilers
Hydraulic Machines and for numerous other applications
Composition
| Sno. | Components | Material |
| 1 | Body & Connector | Cast Iron, SG Iron, Cast Carbon Steel, Stainless Steel, Bronze |
| 2 | Ball | AISI 202, AISI 304, Brass |
| 3 | Stem | AISI 410, AISI 210, AISI 304 |
| 4 | Body & Stem Seals | PTFE (PTFE) |
| 5 | Thrust Washer | M.S. |
| 6 | Handle | M.S. |
| 7 | Handle Sleeve | P.V.C |
| Pressure Testings | Body : 22 Bar (Hydrostatically); 10 Bar (Air) |
| Seat : 16 Bar (Hydrostatically); 7 Bar (Air) |
1 Bar = 0.1 MPa = 1.019 Kg/cm = 14.50 PSI Note : All threads are BSPT/IS:554
Dimensions - Full Bore
| Size | End to End | Bore Diameter | |
| Inch | mm | A | B |
| 1/2 | 15 | 78 | 12.5 |
| 3/4 | 20 | 83 | 19.0 |
| 1 | 25 | 91 | 25.0 |
| 1-1/4 | 32 | 110 | 31.8 |
| 1-1/2 | 40 | 122 | 38.0 |
| 2 | 50 | 137 | 51.0 |
| 2-1/2 | 65 | 160 | 63.5 |
| 3 | 80 | 180 | 76.0 |
| 4 | 100 | 232 | 102.0 |
Note : All threads are BSPT/IS:554 Dimensions for Reduced Bore - On Request
