Semi-automatic Scrap Folding Machine

MANUAL INTRODUCTION OF MACHINE

DOOR OPENING CYLINDER:

1.     Outer Diameter 150 MM.

2.     Inner Diameter 120 MM.

3.     Cylinder Movement 570 MM.

4.     Cylinder Rod Dia 100 MM.

5.     Cylinder Piston Dia 120 MM.

6.     Piston seal Dia 120 MM.

PRESSING CYLINDER:

1.     Outer Diameter 168 MM.

2.     Inner Diameter 145 MM.

3.     Cylinder Movement 1040 MM.

4.     Cylinder Rod Dia 120 MM.

5.     Cylinder Piston Dia 145 MM.

6.     Piston Seal Dia 145 MM.

MOTOR:

  1.     Motor - Kirloskar Made.

  2.     H.P 7.5

  3.     RPM 1440.

  4.     Type-Flange Mounted.

HYDRAULIC VALVE:

 1.     Froward:

 2.     Normal:

 3.     Reverse:

a)     Door open & close cylinder.

b)    Pressing cylinder.

c)     Door lock & unlock cylinder.

d)    Valve maximum Pressure 315 Bar.

e)    Working Pressure 200 Bar.

f)      Valve Inlet & Outlet 3/8 Inches X Inches.

g)     Pressure guage 0 to 600 kgs/Cm3.

h)    Pressure Guage working Pressure.

P C M BLOCK:

1.     Model PCM 20-10-50-315-41-11-13.

2.     Low Pressure- 100 Bar.

3.     High Pressure- 315 Bar.

4.     Low Pressure Tank Line- 25 NB.

5.     High Pressure Tank Line- 19 NB.

6.     PCM Block Outlet- 1Inches X Inches.

HIGH PRESSURE PUMP:

1.     Model- 11R-7C -250.

2.     High Pressure- 0 to 250 Bar.

3.     Flanges 7No.

4.     Number of Element- 7No.

5.     LPM- 8.6 Liter.

6.     Company- Poly Hydron.

LOW PRESSURE PUMP:

1.     Model No 3170.

2.     Low Pressure- 0 to 100.

3.     LPM 32 liter.

4.     Working Pressure- 100 Bar.

5.     Type Gear pump.
