Saybolt Viscometer By Eie Instruments Private Limited

Saybolt Viscometer used for determining the viscosity of petroleum products. Viscosity is measured by determining the time taken by 60 cc of the material to flow through a specified orifice.

GENERAL DESCRIPTION & SPECIFICATIONS :
The apparatus consists of stainless steel bath with oil cup which is centrally placed in a water bath. The bath has a lid which contains a water cooling tube, two handles with two stirring blades, thermometer socket and a straight heater. Stirring is done by turntable arrangement. A thermometer can also be inserted into the cup cover. Two jets one universal and one furol can be screwed to the cup by a handle (without strainer, withdrawal tube and glassware) The temperature is controlled by energy regulator or voltage varrier.(extra cost) Suitable to work on 220V,50 Hz, AC single phase..

OPTIONAL ACCESSORIES:

The following accessories and consumables are not part of the standard supply and are mandatory for the testing work.

Strainer for Filtering Oil.
Withdrawal tube.
Saybolt Viscosity Flask 60 cc.
Glass Thermometer ASTM 17C/18C/19C/20C/21C/22C.
Common Range Thermometer 0-1000C.
Universal Orifice.
Furol Orifice.
