Robust Titling Type Ladder

Our company is widely involve in offering a wide range of Titling Type Ladder that is suitable for electric switch yard, factory, chemical plant & most idle where small gate entry or door do not allow to carry higher length of ladder inside the premises.

Beimco Tilting ladder is best solutions.


Technical Details:


Make


Beimco

Material


Highly Insulated FRP. Pultruded Section

Operation


Winch gear with wire rope

Process


Automatic Pultrusion Plant

Channel Size


75 x 30 x 4.5mm Thickness

Finish


Smooth Finished both sides

Working Load


150 LBS

Channel size


75 x 30 x 4.5mm Thickness

Wheel


14Aca A Dia

Base Width


22Aca A inch. (Approx)

25/32 mm dia aluminum /FRP Pipe

Rung Space


12Aca A Inch

Insulation


Type tested 1oo KV ERDA, Baroda, As per IS 2071/ IEC 60060

Glass Content


65% Glass Content

Base Platform


M.S. Channel

No. of Jack


04 Nos. Jack.





Code


Total Height


Width

BTTL Aca a 4


20 Feet


22 Inch

BTTL Aca a 6


24 Feet


22 Inch

BTTL Aca a 8


28 Feet


22 Inch

BTTL Aca a 10


32 Feet


22 Inch

BTTL Aca a 12


36 Feet


22 Inch

BTTL Aca a 14


40 Feet


22 Inch



Note: Beimco Tilting Ladder Available as per your size & specification.
