Ring Frame Power Presses
Price:
Get Latest Price
In Stock
Product Specifications
| Bolster Area | 760x550x90 mm,980x880x140 mm,1500x840x180 mm,900x600x110 mm,1140x820x160 mm |
| Capacity | 80 Ton,110 Ton,160 Ton,200 Ton,260 Ton |
| Die Cushion Area | 500x350 mm,650x420 mm,810x480 mm,500x350 mm,710x480 mm |
| Die Cushion Capacity | 3.6 Ton,10 Ton,14 Ton,6.3 Ton,14 Ton |
| Die Height | 340 mm,360 mm,460 mm,460 mm,500 mm |
| Features | High performance, Low maintenance, Sturdy build, User friendly, Corrosion resistant, Low running cost, Long lifespan |
| Main Motor | 7.5 kW,15 kW,22 kW,11 kW,18 kW |
| Model | RPA-80,RPA-110,RPA-160,RPA-200,RPA-260 |
| Presses Dimension | 1300x1890x3000 mm,1600x2200x3500 mm,2780x1850x4470 mm,140x1985x3200 mm,1750x2500x3900 mm |
| Presses Weight | 7.8 Ton,17.8 Ton,32 Ton,10.5 Ton,25.3 Ton |
| Slide Adjustment | 80 mm,100 mm,120 mm,120 mm,120 mm |
| Slide Area | 560x420x70 mm,700x550x90 mm,950x700x100 mm,650x470x80 mm,850x630x90 mm |
| Speed | 35-80 spm,30-600 spm,20-50 spm,20-50 spm,20-50 spm |
| Stroke | 150 mm,180 mm,200 mm,200 mm,250 mm |
Product Overview
Key Features
We are one of the leading organizations; engaged in providing Ring Frame Power Presses, which is designed and developed as per the latest technological advancements. This press is widely appreciated for elevated performance, less maintenance, sturdy construction, user-friendliness, corrosion resistance, low running cost and longer service life. Owing to its high quality features, this assortment of Ring Frame Power Presses is widely demanded in the market. It is available in various specifications as per the applications requirements of the clients.
Technical Specifications:
Name | RPA-80 | RPA-110 | RPA-160 | RPA-200 | RPA-260 | ||||||
Model | V | H | V | H | V | H | V | H | V | H | |
Capacity | Ton | 80 | 110 | 160 | 200 | 260 | |||||
Rated tonnage point | mm | 4 | 2 | 6 | 3 | 6 | 3 | 6 | 3 | 7 | 3.5 |
Stoke | mm | 150 | 70 | 180 | 80 | 200 | 90 | 200 | 100 | 250 | 150 |
Die Height | mm | 340 | 380 | 360 | 410 | 460 | 510 | 460 | 510 | 500 | 550 |
Stroke per minute | s.p.m | 35-80 | 80-120 | 30-600 | 60-90 | 20-50 | 40-70 | 20-50 | 50-70 | 20-50 | 50-70 |
Slide Adjustment | mm | 80 | 80 | 100 | 110 | 120 | |||||
Slide Area | mm | 560x420x70 | 650x470x80 | 700x550x90 | 850x630x90 | 950x700x100 | |||||
Bolster Area | mm | 760x550x90 | 900x600x110 | 980x880x140 | 1140x820x160 | 1500x840x180 | |||||
Main Motor | kw.p | 7.5 | 11 | 15 | 18 | 22 | |||||
Slide Adjust device | HP | ELECTRICAL DRIVING | |||||||||
Air Pressure | kg/cm2 | 6 | 6 | 6 | 6 | 6 | |||||
Presses Dimension | mm | 1300x1890x3000 | 140x1985x3200 | 1600x2200x3500 | 1750x2500x3900 | 2780x1850x4470 | |||||
Presses Weight | Ton | 7.8 | 10.5 | 17.8 | 25.3 | 32 | |||||
Presses Precision | |||||||||||
Die Cushion Capacity | Ton | 3.6 | 6.3 | 10 | 14 | 14 | |||||
Stroke | mm | 70 | 80 | 80 | 100 | 100 | |||||
Die Cushion Effective Area | mm2 | 500x350 | 500x350 | 650x420 | 710x480 | 810x480 | |||||
Company Details
Rattan Power Presses Pvt. Ltd. is listed in Trade India's list of verified sellers offering supreme quality of C Frame High Speed, C Frame High Speed Pneumatic Power Press, C Frame Single Point Pneumatic Clutch Power Press, etc. Buy Power Press in bulk from us for the best quality products and service.
Business Type
Exporter, Manufacturer, Supplier
Employee Count
10
Establishment
1963
Working Days
To
GST NO
03AADCR4255N1Z8
