Rheonics Srd Inline Process Density Meter And Viscometer - Accuracy: Density: A A A A 0.001 G/cma A A A

Rheonics Srd Inline Process Density Meter And Viscometer - Accuracy: Density: A A A A 0.001 G/cma A A A

Price: 0.1 INR / Set

Get Latest Price

Minimum Order Quantity :

1 Set

In Stock

Product Specifications

Port Size	1.5 (DN40, Tri-Clamp standard), other sizes available
Accuracy	Density: 0.001 g/cm , Viscosity: 1% of reading %
Operating Voltage	24 VDC Volt (V)
Response Time	<1 second Seconds
Display Type	Digital (interface to external systems)
Temperature	-40 C to +150 C (higher on request) Celsius (oC)
Gas Pressure	Up to 150 bar (custom options available) Bar
Max Height	Sensor Body: 172 mm (without fitting)
Humidity	0-95% RH, non-condensing
Automation Grade	Fully automatic, suitable for integration into process control systems
Resolution	Density: 0.0001 g/cm , Viscosity: 0.1 mPa s
Application	Liquid process monitoring, mixing, blending, quality control, food & beverage, oil & gas, chemicals, pharmaceuticals, ink & paint
Features	No moving parts, maintenance-free, CIP/SIP compatible, IP69K rated, robust stainless steel construction
Interface Type	4-20 mA, RS485 Modbus, HART, Ethernet (optional)
Specimen Size	Inline, not specimen-based Millimeter (mm)
Test Range	Density: 0.5 to 3 g/cm , Viscosity: 1 to 10,000 mPa s
Equipment Type	Inline Process Density Meter and Viscometer
Measuring Range	Density: 0.5 to 3 g/cm ; Viscosity: 1 to 10,000 mPa s Celsius (oC)
Mounting Type	Inline, standard Tri-Clamp fitting
Power Supply	24 VDC, <10 W consumption
Usage	Real-time density and viscosity measurement in-process
Capacity	Designed for continuous inline measurement Kg
Machine Weight	~2.2 kg (sensor only, without flanges) Kilograms (kg)
Control Mode	Automatic, digital output via interface
Payment Terms	Cash Advance (CA), Cash on Delivery (COD)
Supply Ability	2000 Per Week
Delivery Time	10 Days
Sample Available	Yes
Sample Policy	Within a certain price range free samples are available
Packaging Details	yes
Main Export Market(s)	Asia
Main Domestic Market	All India
Certifications	yes
