Rct Basic Magnetic Stirrer

We are authorized distributor & supplier of RCT Basic Magnetic Stirrer in Ahmedabad, Gujarat, India.

Product Details:

Weight2.5 kg
Power Input650 W
Number of Stirring Positions1
Max Stirring Quantity Per Stirring Position20 l (H2O)
Motor Rating Output9 W
Direction of RotationRight
Speed Display Set ValueLED
Speed Display Actual ValueLED
Speed ControlTurning knob
Speed Range50 - 1500 rpm
Setting Accuracy Speed10 rpm
Stirring Bar Length20 - 80 mm
Max Self Heating Of The Hotplate By Stirring28 +K (RT:22deg C/duration:1h)
Heat Output600 W
Temperature Display Set ValueLED
Temperature Display Actual ValueLED
Temperature UnitDeg C
Heating Temperature RangeRoom temp + device self heating - 310deg C
Heat ControlTurning knob
Temperature Setting Range0 - 310deg C
Heating Rate Heating Plate6.5 K/min
Temperature Setting Resolution of Heating Plate1 K
Connection for Ext Temperature SensorPT1000
Temperature Setting Resolution of Medium1 K
Adjustable Safety Circuit50 - 360deg C
Set up Plate MaterialAluminium alloy
Set up Plate DimensionsDiameter 135 mm
Sensor in Medium DetectionYes (Error 5)
Dimensions160 x 85 x 270 mm (W x H x D)
Permissible Ambient Temperature5 - 40deg C
Permissible Relative Humidity80 %
Protection Class AccordingDIN EN 60529, IP 42
Voltage220 - 230, 115 / 100 V
Frequency50/60 Hz

The bestseller in laboratories: Strong motor for a higher range of speeds, additional temperature control mode for faster heating of medium.

Features:
Integrated temperature control
Incl. PT 1000 temperature sensor (PT 1000.60)
Exact temperature and speed setting via digital display, even when switched off
Set safety temperature limit displayed digitally
Hot Top indicator >> hot surface warning to prevent burns!
Digital error code display
With adjustable safety circuit of heating plate temperature (50 - 360 DegreeC)
Safety magnetic stirrer with heating, suitable for unsupervised operation
Bushing according to DIN 12878 for connecting a contact thermometer, e.g. ETS-D5, enables precise temperature control
High level of safety thanks to improved heat control technology
Enclosed assembly (IP 42) guarantees long service life
Aluminium heating plate for optimum heat transfer
Improved magnetic adhesion
Incl. protection cover H 100
