Pv Ribbon Automatic L-shape Reflexed Forming Machine

Our company is engaged in providing an extensive collection of PV Ribbon Automatic L-Shape Reflexed Forming Machine. This equipment is designed by the company independent research and development.mainly for the bending of solar dedicated bus bar.With a rational structure,it can be fastly adjusted, easily operated and precisely controlled. This machine has strong practicability, becoming our domestica s First, solving the bus bar forming processing in pioneering work way.

Model: FL-1
Power Supply: AC220V 210W
Dimensions: (L)1400 * (W) 520* (H) 1200 (mm)
Weight: 120KG
Number of strip processed:1pc
Forming length:the short side is 0-100 mm, the long side :Any length
Forming angle:90A A 5A
Cutting width :1-10mm
Cutting thickness: 0.10-0.50 mm
Cutting accuracy: A (0.2+L*0.002)mm

Processing speed: L=220mm,10pcs/min
