Purge Panel - Mild Steel, Powder Coated Finish | Iec 60079-2 & Nfpa 496 Standard, Type X, Y, Z Variants Available

We are a reputed name in this industry as a Exporter, Manufacturer & Supplier of Purge Panel in Mumbai, Maharashtra, India. These are mainly classified in to main three categories
Type a X a
Type a ya
Type a Za

The industrial standards are followed while manufacturing the purge panels
We provide all three categories ( X type, Y type, Z type purge ) as per customer & plant requirement.
Type "X" Protects general purpose equipment in Division 1 Areas This system reduces the classification within protected enclosures from Division 1 to nonhazardous.
It is required to automatically control electrical power to all protected equipment.

Type "Y" Protects Division 2 rated equipment in Division 1 Areas This system reduces the classification within protected enclosures from Division 1 to Division 2. All protected equipment must be rated for Division 2. Automatic power control disconnects are not required, but visual and/or audible alarms must be initiated when there is loss of pressure.

Type "Z" Protects general purpose equipment in Division 2 Areas This system reduces the classification within protected enclosures from Division 2 to non classified.

Automatic power control disconnects are not required, but visual and/or audible alarms must be initiated when there is loss of pressure

We provide purge panels using P& F make 6000 series purging system for X purge We also provide purging arrangements for ready made enclosures by doing modifications
