Profile Projector

Get Latest Price

Brand Name :

Nano Scan

In Stock

Product Specifications

Projection Screen Size	150mm-300mm
Magnification	10x-100x
Light Source	LED
Measurement Accuracy	0.01mm
Power Consumption	100W
Weight	50kg
Usage	Measuring parts in automotive, engineering, forging and foundry industries
Features	Precise Measurement, Compact Design, Energy Efficient, Low Maintenance, Versatile Use

Product Overview

Key Features
