Pressure Gauges - Pgmb

We are offering our customers a wide range of Pressure Gauges - PGMB, which are available following Specifications :-
PGMB : Mild Steel Pressure Gauge with Brass Internals
Model : PGMB
Type : Utility
Dial Size : 1.5" - 12"
Range : -760mmHg to 1000 bar
Wetted Parts : Copper Alloy
Case : Powder Coated MS

Special Features :
Economic Version
General Purpose Application
Accuracy upto A 1.0%
Applications :
Mainly for Water / Air Application, Pharmaceutical Industries, petrochemical industries, Power, Cement, Sugar, Food, Beverages, Paper and Pulp Industries and Allied Process Industries.
Specifications :
Standard Version: 40mm, 50mm, 63mm, 100mm, 150mm, 250mm
Accuracy : A 1.6% of F.S. for 100mm, 150mm and 250mm
A 2.0% of F.S. for 50mm, 63mm
A 2.5% of F.S. for 40mm
Ambient temperature : - 25 oC to + 65 oC
Process temperature : Max 180 oC
Operating pressure : 75% of the Scale Value
Over pressure limit : 30% for Pressure Ranges upto 600 kg / cm2
15% for Pressure Ranges above 600 kg / cm2
Case : Mild Steel, Black powder coated
Ring : Mild Steel, Black powder coated
Bourdon : Copper Alloy
Socket : Copper Alloy
Movement : Copper Alloy
Joints : Silver Brazing / Alloy Brazing
Protection : IP 65
Dial : Aluminium, black graduation on white background
Pointer : Aluminium, black coloured Micrometer zero adjustable
Window : Sheet Glass
Blow off Disc : Neoprene
Gasket : Neoprene
