Precision Digital Multimeter Et1260

6A 1/2 BIT Precision Digital Multimeter ET1260 Details:-

Digital multimeter is widely used in the field of electronic testing
Modern digital multimeter with high precision, high speed, high input impedance, digital display, the accuracy of reading, the advantages of strong anti-interference ability and high measure the degree of automation, and therefore is widely used, gain the favour of engineers.
ET12 multimeter equipped with 3.5 inch high resolution color display series, embedded intelligent operating system, it can provide more information, more functions, simple operation, more wide test range, construction of the system is more flexible and convenient, it is to lead the development trend of new type digital multimete
Our products have double benchmark calibration function, users only need one 10 v voltage and one 10 k IC standard resistor can realize all the functions of calibration, the user through the calibration of the machine of time less 1 hour.


Modelinstructions
ET1260B6A 1/2 bit precision digital multimeter, GPIB interface, rear panel signal input terminal.
ET1260A6A 1/2 bit precision digital multimeter, without GPIB interface, without rear panel signal input terminal.


1A A A A A A A A Basic features


6 1/2 resolution (ET1260B/ETET1260A)
The digital multimeter is equipped with a 3.5-inch color display screen (resolution ratio is 320*480), which is powerful enough to provide greater coverage of content, flexible display of a variety of graphical interface, and good display effects. The users can also customize the display interface depending on their needs, and choose from various display functions such as graphics, figures, maths and other functions simultaneously on the screen.
Bi-parameter display can display two parameters in one input signal (such as display AC voltage value and AC frequency value during AC voltage measurement).
Conduct remote operation through interfaces of IEEE 488 (ET1260B), RS-232, LAN and USB Device.
With functions of trigger input and output of measuring completion.
The front-panel menu is with USB port for data storage, procedure updating and configuration.
Customers can update host software by themselves.
Two-wire and four-wire measurement for resistance, 10IC and 1GIC measurement range for extension.
Measurement of period and frequency, and frequency can reach to 300 kHz.
Capacitance measurement.
For temperature measurement, users can set sensor measurement by themselves.
Maximum current measurement capacity reaches up to 12A.
Many math functions: statistics (maximum value, minimum value and average value), zero elimination, dB, dBm and limit.
Graphic display: tendency chart, histogram, history curve, listing and other display methods.
Support SCPI programming language and many command sets (Agilent 34401A and Fluke 45).
With internal and external calibration functions.
A A A A A A A A A A A A A A
2A A A A A A A A A Main technical indicators

ModelET1260BET1260A
display3.5-inch color screen (resolution 320*480)
According digits6A 1/2
Signal terminalfront-end/back-endfront-end
Maximum measurement speed2500 readings per second
functionItemsuncertaintyi A (% measurement + % range)
A
DCV
A uncertainty0.0035+ 0.0005
Measuring range0 mV~1000 V
Maximum resolution100nV
A
A
ACVuncertainty0.06 + 0.03
Measuring range1 mV~750 V
Maximum resolution100nV
Frequency range3 Hz ~ 300 kHz
A
DCIuncertainty0.05 + 0.006
Measuring range0 uA ~ 12 A
Maximum resolution10 pA
