Air Plasma Powermax125 - Automatic Grade: Semi-automatic

Cutting capacity Capacity Thickness The cutting speed Recommended 25 mm 500 mm/min 32 mm 250 mm/min Separation (manual cutting) 38 mm 125 mm/min Pierce (Drilling)* 20 mm *Drilling specification for manual or mechanized cutting with programmable torch height control. Maximum removal gouging Capacity Metal removal rate Gouge profile Common gouging 8.2 kg per hour 3.5mm L x 6.6mm W General specifications Input voltages CSA 200"480V, 1Ph, 50/60Hz 200"600V, 3Ph, 50/60Hz EC 380"400V, 3Ph, 50/60Hz Output in kilowatts 12.2 kW Input current CSA 200/208/240/480 V, 1F 70/68/58/29 A at 12.2 kW 200/208/240/480/600V, 3F 42/40/35/18/17A @ 12.2KW EC 300/400V, 3Ph 20.5/19.5A Output current 25"85 A Nominal output voltage 143 VDC Duty cycle at 104F CSA 60% at 85 A, 230"600 V, 3P 60% @ 85A, 480V, 1Ph 50% at 85A, 240V, 1Ph 50% at 85 A, 200"208 V, 3P 40% @ 85 A, 200"208 V, 1Ph 100% at 66 A, 230"600 V, 1/3F EC 60% at 85 A, 380"400 V, 3P 100% @ 66 A, 380"400 V, 3P Open Circuit Voltage (OCV) CSA: 305 VDC CE: 270 VDC Dimensions with handles 483mm L; 233mm W; 430mm H Weight with 7.6m torch CSA: 32 kg CE: 23.5 kg Gas supply Clean, dry, oil-free air, or nitrogen Ideal gas inlet pressure 7.6"8.3 bar Minimum gas inlet pressure 5.2 bar Recommended inlet gas flow rate range Cut: 210 L/min at 5.9 bar Gouging: 210 L/min at 4.8 bar Input power cable length 3 m Power supply type Inverter - IGBT (insulated gate bipolar transistor) Motor power specification 20 kW for 85 A total output Electrical efficiency 91.9 % Certifications CSA certified for use in the Americas and Asia, excluding China CE " for use in Europe, Australia, New Zealand, Belarus, Serbia, Ukraine and other countries where these certifications are accepted. Also RCM, Ukraine and Serbia. UKCA " Great Britain Guarantee Power supplies have a three-year warranty and torches have a one-year warranty
