Powder Dynamometers
Powder Dynamometers, as their name suggests, contain magnetic powder in Dynamometer. The electrical current passing through the coil generates a magnetic field, which changes the property of the powder from free flowing condition at no excitation, to solid rock condition at full excitation. Thus producing a smooth braking torque through friction between rotor and stator a proportional to excitation.
The Powder Dynamometers produces their rated torque at zero speed.
The element to be tested can be loaded at standstill to determine the starting torque. Powder Dynamometer achieves at low control power, a high torque being independent from the slip speed. It distinguishes itself by a simple construction, low weight and small required space. Powder Dynamometers are ideal for applications operating in the low to mid speed range and mid to high torque range up to 3000 KgM (30000 Nm) of torque. For higher heat dissipation Powder dynamometers are provided with water circulation system for cooling, which passes inside the stator to dissipate heat generated by the braking power with power ratings up to 160 kW. They have system accuracy ratings of typically +/- 0.5% full scale, depending on Dynamometer size and system configuration By changing the exciting power force, the torque to be transmitted can be adjusted infinitely variable in the range 1:50. Powder dynamometers are typically limited to lower RPM due to heat dissipation issues
The mounting structure to accommodate the device under test, Torque & Speed transducer and Dynamometers is a sturdy mechanical structure designed for low vibrations. Safety guards for all the rotating elements are provided on the test bed with interlocks for safe operation.Test bed with T slot having X, Y & Z adjustment for Length, Width & Height adjustments is also offered along endurance test rig
Powder Dynamometers, as their name suggests, contain magnetic powder in Dynamometer. The electrical current passing through the coil generates a magnetic field, which changes the property of the powder from free flowing condition at no excitation, to solid rock condition at full excitation. Thus producing a smooth braking torque through friction between rotor and stator a proportional to excitation.
The Powder Dynamometers produces their rated torque at zero speed.
The element to be tested can be loaded at standstill to determine the starting torque. Powder Dynamometer achieves at low control power, a high torque being independent from the slip speed. It distinguishes itself by a simple construction, low weight and small required space. Powder Dynamometers are ideal for applications operating in the low to mid speed range and mid to high torque range up to 3000 KgM (30000 Nm) of torque. For higher heat dissipation Powder dynamometers are provided with water circulation system for cooling, which passes inside the stator to dissipate heat generated by the braking power with power ratings up to 160 kW. They have system accuracy ratings of typically +/- 0.5% full scale, depending on Dynamometer size and system configuration By changing the exciting power force, the torque to be transmitted can be adjusted infinitely variable in the range 1:50. Powder dynamometers are typically limited to lower RPM due to heat dissipation issues
The mounting structure to accommodate the device under test, Torque & Speed transducer and Dynamometers is a sturdy mechanical structure designed for low vibrations. Safety guards for all the rotating elements are provided on the test bed with interlocks for safe operation.Test bed with T slot having X, Y & Z adjustment for Length, Width & Height adjustments is also offered along endurance test rig
Explore in hindi - पाउडर डायनामोमीटर
Company Details
APPLICATION SYSTEMS is established in year 2000 at Thane, near Mumbai, manufacturing, various types Dynamometers to test Engines, Motors, Gears & Gear Boxes, Shafts & Axles, Chassis etc. Magnetic Powder Brakes & Clutches, Web Tension Control systems, Load Cells, Welding back up strips & Tapes,
1) Dynamometers - Eddy Current Dynamometers, Powder Dynamometers, Pneumatic Dynamometers, Tandem Dynamometers, AC Regen Dynamometer, Engine Dynamometers, Motor Test Dynamometers, Chassis Dynamometer, Test Benches, Test Rigs.
2) Magnetic Powder Brakes & Clutches - Powder Brakes & Clutches are manufactured in wide rating range, form tiny 0.1 KgM (1 Nm) to Massive 500 KgM (5000Nm), in various cooling versions such as Self Cooled, Forced Air cooled, Fan Cooled & Water Cooled. These are true Torque Control Devices. Torque is strictly proportional to Excitation Current applied to Coil. These devices come with matching electronics to meet your most exacting applications such as Torque Control, Tension Control, Stretch Control, Torque Limit & many more.
3) Web Tension Control systems - Web Tension Control systems for Unwind, Rewind & Intermittent section. Web tension control consist Load cell feed back as well as diametric compensation for accurate tension control. Web Tension Control systems configured using either Motorised or Powder brakes & Clutches.
Tension Controls are used mainly for: UNWIND, PAY OFF, REWIND, TAKE UP INFEED, OUTFEED & Intermittant Sections
For printing machine,
For Lamination & coating machines,
For Slitting machine,
For Wires & Cable machine, Wire cut machines,
For Paper, Plastic Films, Foils, Wires, Cables converting machines,
4) Load cells.- Web Tension Load Cell- Web Tension Sensing Load Cells, Weighing Load Cell, Reaction Torque measurement Load Cells.
5) Welding back up tape - CERBACK Brand Welding back up tapes & strips for one side welding. These are used for ALL kind of WELDING PROCESSES & for ALMOST ALL METALS, for One Side welding. Welding processes such as SMAW, FMAW, GMAW, SAW, CO2, TIG, MIG etc.
By using Weld back up strips, Welding COST is saved approx 50 to 60% whereas welding TIME is saved by 50%. RESULTS are 100% RADIOGRAPHIC WELDING. No Back CHIPPING, No Back GRINDING or Gouging, No PURGING required.
