Post Forming Machine - Steel, Dimensions 3600x660x1275 Mm | Easy Operation, High Accuracy, Modular Design, Increased Productivity

One of our specialities is that our Post Forming Machines are in high quality, Heavy duty, Economical comparing to others. Best assurance is given for Quality, Guarantee and after sale-service to our Wood Working Machineries.

The company offers viable solutions to difficult challenges in ensuring stringent quality standards & ensuring cost competitive production.

Post Forming Machinery - a flagship product of Ruei Industries

Model No : RI 3100

These machines are used for make various types of furniture. The Machine is used for place laminates on a profiled work piece and shapes automatically the laminate to the profile of work piece by applying required pressure on the forming rail. Our machines can take up a maximum work piece having a length of 2600mm.

TECHNICAL SPECIFICATIONS

Maximum Length of work piece : 2600 mm
Workpiece Thickness : 16 / 100 mm
Maximum Workpiece Width : 200 mm
Maximum Heating Temperature : 200o C
Heating Elements : 3 KW
Electric motor 3 Phase : 0.5 HP
Machine Dimension ( l x b x h ) : 3600 x 660 x 1275
Approximately Weight : 1100 Kgs
Compressed air Requirement : hp / kg cm2 3/7
