Portable Fiberscope

Price:

Get Latest Price

In Stock

Product Specifications

Probe Length	2 meters
Probe Diameter	8 mm
Camera Resolution	4.84 MP
Field of View	100 degrees
Light Source	LED
Battery Type	Lead Acid
Display Size	5 inch
Weight	5 kg
Usage	Inspecting pipes and engines
Operating Temperature	-20°C to 65°C
Storage Capacity	2 GB
Warranty	3 years
Features	Portable inspection, Video display, Flexible probe, Durable design, Clear images

Product Overview

Key Features

In order to
provide complete satisfaction to the clients, we are offering to them a huge
stock of Portable Fiberscope. The
range of fiberscope is especially made for the applications of inspecting fine diameter
pipe work and small engines. All our devices are well integrated with the high
quality materials sourced from reputed vendors of the market. We deliver the array
of Portable Fiberscope to customers at highly feasible rates.

Features:

Integrated with
video monitor
Technically assorted
Highly protective

Further Details:

PORTABLE FIBROSCOPE ( WITH HAND HELD HELD MONITOR )

------------------------------------------------------------------------------------------------

General:

Portable fibroscope search equipment with video monitor and endoscopic probe Endoscopic probe, Flexible , Protective and crush resistant, coiled steel sheath with PVC coating for optic fiber cable. Fuel / organic solvent / water / chemical resistant.

Insulated and electric shock proof resistant. Effective length 2 meter , Outer diameter 8 mm

Search Heads :

has miniature CCD Camera & 2 LED light source to view narrow, deep and dark cavities through the small aperture.

Camera :

4.5mm , colour miniature CCD camera, housed within the search head tip with 4.84 mega pixels resolution.

Lens:

FOV 100 degrees. The depth of field of view is 5 mm 120 mm . Additional wide angle optical tip is provided with conventional optical tip.

Cold light source, LED , bright enough to give clear images of objects placed in deep cavities.

Battery:

12V Lead Acid SMF rechargeable battery.

Dimensions of control unit :

approx 300 mm x 200 mm x 125 mm

Lamp life :

approx 5000 hours. , with brightness control . Additional spare lamps also provided.

Display monitor:

Light weight TFT-LCD colour monitor 5 inch installed on the hand held unit. Controls Integrated with display monitor

Probe Search head articulation in four directions , at 93 degrees. Optical magnification is 11X .

2 GB card capacity to store above 1100 images. It has facility of video image processing in inbuilt memory . The data card is easily removable from the control unit without using any tools

Works on PAL / NTSC option

Power source AC power 160 V to 250 V; 50 Hz

DC Power Rechargeable battery ( Li-ion/ Ni-mh ) Battery of 2.5 hours operations each with one extra spare battery provided . Approx weight of battery : 300 grams

Battery charging level indicator along with status of charging on the charger is indicated

Push to On / Off switch for continuous operation . Membrane key pads for detailed controls

Connection for image / video display in external monitor through wire.

Equipment is shock / vibration proof , capable of operations at -20 deg C to + 65 deg C, Humidity : upto 95% (non-condensing)

Weight of equipment:

approx 5 Kgs.

Carrying case:

Weather proof, shock proof moulded carrying case lined with protective foam.

Warranty 3 years. Sufficient spares are available in stock and future availability till 7 years from date of supply after the warranty period.

Training tools , Technical manual , Practical training , User's handbook & literature on preservation / maintenance of equipment provided , along with procedure for packing, handling, transportation and storage with equipment.

Fully meeting MHA Specifications
		Customization as per user requirement possible
