Pentra Prisms
Price:
Get Latest Price
In Stock
Product Specifications
| Material | N-BK7 glass |
| Dimension Tolerance | +0.0,-0.2mm |
| Surface Quality | 60-40 S/D |
| Surface Flatness | /4 @ 632.8nm |
| Angle Tolerance | 30 arc sec |
| Clear Aperture | >85% |
| Bevel | <0.25mm |
| Coating | MgF2, Aluminized |
| Usage | Image deflection and beam steering in optical systems |
| Features | Precise angles, Durable coating, High precision, Optical glass, Image rotation |
Product Overview
Key Features
We are engaged in offering excellent quality Pentra Prisms to our valuable clients. The deviation angle of 90A is thus independent of the orientation of the prism, making it especially important in applications in which the prism orientation cannot be precisely controlled. Due to geometry that total internal reflection cannot be used, the reflecting surfaces must be coated with a metallic or dielectric coating. The standard Penta Prism reflecting surfaces are coated with aluminum or enhanced aluminum. Sometimes, the coated surfaces are with black painting.
Specifications:
Material: N-BK7 or other optical glass
Dimension Tolerance: +0.0, -0.2mm
Surface quality: 60-40 S/D
Surface flatness: I /4 @ 632.8nm
Angle Tolerance: A 30 arc sec(Standard); A 5 arc sec(High Precision)
Clear Aperture: >85% of dimension
Bevel: <0.25mmA 45A
Coating: Surfaces S1 & S2 :Single layer MgF2 coating
Surfaces S3 & S4: Aluminized and painted black
Specifications:
Material: N-BK7 or other optical glass
Dimension Tolerance: +0.0, -0.2mm
Surface quality: 60-40 S/D
Surface flatness: I /4 @ 632.8nm
Angle Tolerance: A 30 arc sec(Standard); A 5 arc sec(High Precision)
Clear Aperture: >85% of dimension
Bevel: <0.25mmA 45A
Coating: Surfaces S1 & S2 :Single layer MgF2 coating
Surfaces S3 & S4: Aluminized and painted black
Company Details
WTS PHOTONICS CO., LTD., Established in 2000 at Fuzhou in Fujian, is a leading Exporter,Manufacturer,Supplier of Optical Instruments & Devices in China. WTS PHOTONICS CO., LTD. is one of Trade India's verified and trusted sellers of listed products. With extensive experience in supplying and trading Pentra Prisms, WTS PHOTONICS CO., LTD. has made a reputed name for itself in the market with high-quality Achromatic Lenses, Ball Lenses, CaF2 Windows, etc.
Focusing on a customer-centric approach, WTS PHOTONICS CO., LTD. has a pan-India presence and caters to a huge consumer base throughout the country. Buy Optical Instruments & Devices in bulk from WTS PHOTONICS CO., LTD. at Trade India quality-assured products.
Focusing on a customer-centric approach, WTS PHOTONICS CO., LTD. has a pan-India presence and caters to a huge consumer base throughout the country. Buy Optical Instruments & Devices in bulk from WTS PHOTONICS CO., LTD. at Trade India quality-assured products.
Business Type
Exporter, Manufacturer, Supplier
Establishment
2000
