Paint Booth Hx-600 - 7000x5560x3430 Mm Dimensions | Eps Panel, 22000 Mâ³/h Air Circulation, 98% Dust Filtration, Diesel Heating System

Backed by a team of diligent experts, we have been able to manufacture, export and supply a wide range of Paint Booths in Faridabad, Haryana, India.

Product Specifications/Features :

Paint Booth HX-600

1.Size:

Outside Size (mm) : 7000x5560x3430 (LXWXH)

Inside Size (mm) : 6900A 4000A 2800 (LXWXH)

2.Wall panel:

EPS (epispastics polystyrene)Colorful Steel Skin

Boards, 50mm Thick, Compound Construction, Anti-flame and

Heat-Insulation, Handiwork Door, Galvanized Steel Roof Panel

3.Basement:

Two Grid& Three Embossed Plate, Galvanized Steel Sheet

Construction, Two Ramps,

4.Air Circulation System:

Inlet Fan: Blower capacity: 22000m3/h; Power: 4kw/set;

Quantity: 2 sets

NO Outlet Fan

Air Volume: 22000m3/h; Air Speed: 0.35m/s; Air Recycling

times:280 times/h;

5.Purification System:

Ceiling Filter Capture Granules Bigger than 5I m. The

Whole Purification System Has Capacity of Large Volume of

Dust. Its Filtering Rate Reaches 98%. TSPa 1.4mg/m3

6.Heating system:

Riello Brand diesel burner, 260000Kcal/h, SUS304 stainless steel heating exchanger, argon arc welding;

Max temp:80 degrees Celsius, heating time: 4-6min(20-60 degrees Celsius),

Fuel consumption:4-5kg/vehicle
