Syno Packaging Machine

Following are the Technical Specifications of Packaging Machine :-
Model : Oil Pack 16ss
Product : Oil, Vanaspati & Ghee
Packaging Material : Multi-Layer Nylon Based Films
Type of Seal : Side Seal
Width of the Film : 325mm
Size of the Pouch : 250mm (L) x 162.5mm (W)
Machine Speed : 18 Pouches per minute
Accuracy : + 1 grm. Per 1000 grms.
Dosage : Upto 1 Ltrs. (or) 1 Kg.

Optional Accessories
Photocell Registration
Batch Coding
Voltage Stabiliser
Water Cooler
Take off Conveyor

Salient Features
Fully automatic with electronic controls.
Easy Access to control points.
Simple for Maintenance.
No more any contactors and relays in CKT.
Pouch length controlled by Electro Magnetic Device.
MS Fabricated Body with SS Cladding.
Improved heat control system ensures good sealing
Horz. Band sealing of 4mm width on each side ensures less chances of leakage.

Utility of the Machine
Electrical : 415 Volts, 50 Hz. 3 Phase or 230 Volts, 50 Hz. 1 Phase
Power Consumption : 2.5 Kw per hour
Peak Power Rating : 3.9 Kw per hour
Cooling Water : 10oC, 30 PSI min. 165 Ltr./Ph
Overall Dimension : 2500 (H), x 1000 (W) x 1200 (D) All in mm.
