Multi Viewing Microscope - Precision Optical Glass, Adjustable Magnification Levels | Enhanced Viewing Experience, Versatile Multi-angle Observations

Price:

Get Latest Price

Brand Name :

Edutek

In Stock

Product Specifications

Spare Parts	Supplied with dust cover, fuses, immersion oil, user manual; eyepieces and bulbs available as accessories.
View Head	Main head and multiple side heads, semi-plan or plan viewing prisms for simultaneous observation.
Focus System	Coaxial coarse and fine focusing with tension adjustment.
Features	Multiple viewing attachments (up to 10 observers); pointer for instruction; anti-fungal optics; ergonomic design for teaching and demonstrations.
Theory	Other, Designed for simultaneous observation by multiple users for teaching, discussion, or collaborative research.
Drawtube	Other, Trinocular and multiple viewing heads (typically up to 5-10 viewers), lateral viewing attachments provided.
Sensor	Camera mount compatible (CCD/CMOS, not included as standard).
Resolution	Depends on camera; optical system typically provides high-resolution imaging suited for educational and laboratory use.
Interface	Standard camera interface port; eyepiece tubes for direct observation.
Frame Rate	Depends on camera (not applicable to optical units).
Focal Distance	160 mm mechanical tube length (standard for most multi-viewing systems).
Magnification	40x to 1000x (using four-position nosepiece with 4x, 10x, 40x, 100x objectives).
Dimensions	Approx. 500 x 300 x 270 mm (varies by configuration).
Focus Range	Coarse and fine focus adjustment; standard travel range up to 30 mm (coarse), 0.002 mm precision (fine).
Eyepieces	Wide field WF10x/18mm (anti-fungal, high eyepoint design for glasses wearers), swappable with optional magnifications.
Eyepiece Tube	Inclined at 30Adeg, rotatable 360Adeg, multi-head bridge with pointer for main observer.
Illumination	Built-in adjustable LED or halogen light source (6V/20W halogen standard; upgradeable to LED in some models).
Coarse Adjustment Range	30 mm total travel (approximate).
Fine Adjustment Range	0.002 mm per division.
Working Stage	Double layer mechanical stage, size approx. 140 A-- 140 mm, with 75 A-- 50 mm movement.
Still Image Capture Resolution	Up to camera specifications; optical system supports high-res capture through camera port.
Video Capture Resolution	Depends on camera selection (e.g., 720p, 1080p, or higher with compatible camera).
Image Format	Depending on camera used (JPG, BMP, TIFF, etc. for digital systems).
Interpupillary Distance	55 to 75 mm adjustable for all observers.
Objective Achromatic	DIN achromatic objectives: 4x, 10x, 40x (S), 100x (S, Oil Immersion).
Condenser	Abbe condenser NA 1.25, with iris diaphragm and filter holder.
Light Source	Halogen 6V/20W (standard) or LED (if specified); with brightness control.
Payment Terms	Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
Sample Available	Yes
Sample Policy	Sample costs shipping and taxes has to be paid by the buyer
Packaging Details	carton box, export quality also available
Main Export Market(s)	Asia, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market	All India
Certifications	ISO 9001, 14001 ,CE
